Reamer Shoe
ASTA Reamer Shoe is designed for various sizes of casing and borehole. This product is applicable for large diameter casing string with either hydraulic or mechanically set hangers.
The Reamer Shoe is made in compliance with API RP 10 F. The nose area is constructed using high quality material and can be easily drill by both PDC and Tri-cone rock bit.
This product includes the following 2 types of Tungsten Carbides: Chunky Grain Type and Button Insert Type. ASTA Reamer Shoe is available in various sizes with API-5CT standard thread.
| Casing Size | Hole Size | Max Tool OD | Casing Weight | Blades |
|---|---|---|---|---|
| 5 | 6 | 5.8 | 18 # ~ 23 # | 4 ea |
| 5 | 8-1/2 | 8.3 | 18 # ~ 23 # | 4 ea |
| 5-1/2 | 8-1/2 | 8.3 | 17 # ~ 26 # | 4 ea |
| 7 | 8-1/2 | 8.3 | 23 # ~ 29 # | 6 ea |
| 7 | 8-1/2 | 8.3 | 32 # ~ 38 # | 6 ea |
| 9-5/8 | 12-1/4 | 12 | 43.5 # ~ 68 # | 6 ea |
| 13-3/8 | 17-1/2 | 17.3 | 54.5 # ~ 103.1 # | 6 ea |
Notes:
Other size and type of cutter structure are available based on request
(*) Available in Left and Right hand spiral direction
Ordering Suggestions
1. Casing size, weight and type of thread connection.
2. Hole size or max tool OD size
3. Type cutting structure and blade direction
Other size and type of cutter structure are available based on request
(*) Available in Left and Right hand spiral direction
Ordering Suggestions
1. Casing size, weight and type of thread connection.
2. Hole size or max tool OD size
3. Type cutting structure and blade direction
Product Picture
